SLS 114RT-I-PXO Point Source Speaker
Liên hệ để báo giá
The SLS 114RT-I-PXO is a passive, high-quality, full-range two-way speaker, designed as a multipurpose system for situations where highly accurate, high system-output levels are required .
The SLS ll4RT-I-PXO features the high-powered, high-output PRD1200 high-frequency ribbon driver, and a 700 Watt 14” woofer with a neodymium magnet structure. The PRD1200 ribbon driver is mounted on a rotatable 80˚ x 30˚ waveguide, allowing the speaker to be installed vertically or horizontally as needed. Replace this sentence with; Due to the high-power handling and low mass of the ribbon driver diaphragm, the speaker reproduces audio at exceptional transient response and clarity. The result is openness, responsiveness, and accuracy with high levels of system intelligibility. The 114RT-I-PXO provides solid low-frequency performance down to 42 Hz, and coupled with a subwoofer, provides exceptional broad-bandwidth system fidelity at high-performance levels.
The 114RT-I-PXO is fitted with fly-points and mounting points for a wall-mount bracket, have no handles or pole-sockets, and are provided with barrier-strip inputs.
Features
- Two-way with 700 W (continuous) 14” woofer, rotatable high-output PRD1200 planar ribbon driver, trapezoid cabinet
- Equipped with passive crossover
- Coverage angles (-6 dB; H x V): 80° x 30° (rotatable)
- Operating range: 42 Hz to 20 kHz
Specifications
-
OPERATING RANGE (-10DB)
42Hz to 20kHz
-
FREQUENCY RESPONSE (+/-3DB)
52 Hz to 20kHz
-
COVERAGE ANGLE (-6DB) HORIZONTAL
80°
-
COVERAGE ANGLE (-6DB) VERTICAL
30°
-
NOMINAL IMPEDANCE
8Ω
-
SENSITIVITY 1W@1M
99dB
-
SENSITIVITY 2.83V
99dB
-
MAXIMUM USEABLE CONTINUOUS OUTPUT
123dB
-
MAXIMUM USEABLE PEAK OUTPUT
129dB
-
LONG TERM CONTINUOUS POWER RATING
700W/66.5V
-
TRANSDUCERS LOW
14″ Bass/Midrange
-
TRANSDUCERS HIGH
PRD1200 6″ Ribbon 80° Waveguide
-
ENCLOSURE MATERIAL
13-Ply Baltic Birch
-
FINISH
Black Latex, White Latex, or Natural
-
GRILLE
Color-matched powder-coated steel; Black, White (Black for Natural)
-
INPUTS
Barrier-Strip
-
RIGGING
12 Points 3/8″ Threaded Inserts, 4 Points 1/4″ / 20 Inserts
-
UNIT DIMENSIONS
29.2″ H 16.9″ W 18″ D (74.2cm H 42.9cm W 45.7cm D)
-
UNIT WEIGHT
67 lbs (30.39 kg)
-
SHIPPING DIMENSIONS
23″ x 24″ x 35″ (58.42 x 60.96 x 88.90 cm)
-
SHIPPING (GROSS) WEIGHT
71 lbs (32.21 kg)
