Trang chủ / Cinema / Audio / Cinema Loudspeaker

SLS 114RT-I-PXO Point Source Speaker

Liên hệ nhận báo giá

The SLS 114RT-I-PXO is a passive, high-quality, full-range two-way speaker, designed as a multipurpose system for situations where highly accurate, high system-output levels are required .

Danh mục: Âm thanh, Cinema Loudspeaker Từ khóa: 114RT-I-PXO, Dolby, Dolby SLS 3-Axis Speaker MA480AS, Point, SLS, Source
Danh mục sản phẩm
  • Loa siêu trầm
  • Loa vòm
  • Extension
  • Phụ kiện
  • Loa dàn cong
  • Bộ xử lý âm thanh
  • Loa bi-amp
  • Loa nguồn điểm
  • Loa toàn dải
  • Loa dàn
  • Âm thanh
  • Subwoofer
  • Ánh sáng
  • Stage monitor
  • samsung onyx cinema
  • Loa kiểm âm sân khấu
  • Loa tri-amp
  • Cinema
    • MX4D Theatre
    • Projector
    • Media Server
    • Audio
      • Cinema Amplifier
      • Audio Processor
      • Cinema Loudspeaker
        • LCR Screen Speakers
        • Subwoofer
        • Surround Speakers
  • Accessories
  • BGM & PA
  • Lighting Stage
  • Pro Sound
  • Mô tả
  • Đánh giá (0)

The SLS ll4RT-I-PXO features the high-powered, high-output PRD1200 high-frequency ribbon driver, and a 700 Watt 14” woofer with a neodymium magnet structure. The PRD1200 ribbon driver is mounted on a rotatable 80˚ x 30˚ waveguide, allowing the speaker to be installed vertically or horizontally as needed. Replace this sentence with; Due to the high-power handling and low mass of the ribbon driver diaphragm, the speaker reproduces audio at exceptional transient response and clarity. The result is openness, responsiveness, and accuracy with high levels of system intelligibility. The 114RT-I-PXO provides solid low-frequency performance down to 42 Hz, and coupled with a subwoofer, provides exceptional broad-bandwidth system fidelity at high-performance levels.

The 114RT-I-PXO is fitted with fly-points and mounting points for a wall-mount bracket, have no handles or pole-sockets, and are provided with barrier-strip inputs.



Features

  • Two-way with 700 W (continuous) 14” woofer, rotatable high-output PRD1200 planar ribbon driver, trapezoid cabinet
  • Equipped with passive crossover



  • Coverage angles (-6 dB; H x V): 80° x 30° (rotatable)
  • Operating range: 42 Hz to 20 kHz



Specifications

  • OPERATING RANGE (-10DB)

    42Hz to 20kHz

  • FREQUENCY RESPONSE (+/-3DB)

    52 Hz to 20kHz

  • COVERAGE ANGLE (-6DB) HORIZONTAL

    80°

  • COVERAGE ANGLE (-6DB) VERTICAL

    30°



  • NOMINAL IMPEDANCE

    8Ω

  • SENSITIVITY 1W@1M

    99dB



  • SENSITIVITY 2.83V

    99dB

  • MAXIMUM USEABLE CONTINUOUS OUTPUT

    123dB



  • MAXIMUM USEABLE PEAK OUTPUT

    129dB

  • LONG TERM CONTINUOUS POWER RATING

    700W/66.5V



  • TRANSDUCERS LOW

    14″ Bass/Midrange

  • TRANSDUCERS HIGH

    PRD1200 6″ Ribbon 80° Waveguide



  • ENCLOSURE MATERIAL

    13-Ply Baltic Birch

  • FINISH

    Black Latex, White Latex, or Natural



  • GRILLE

    Color-matched powder-coated steel; Black, White (Black for Natural)

  • INPUTS

    Barrier-Strip



  • RIGGING

    12 Points 3/8″ Threaded Inserts, 4 Points 1/4″ / 20 Inserts

  • UNIT DIMENSIONS

    29.2″ H 16.9″ W 18″ D (74.2cm H 42.9cm W 45.7cm D)



  • UNIT WEIGHT

    67 lbs (30.39 kg)

  • SHIPPING DIMENSIONS

    23″ x 24″ x 35″ (58.42 x 60.96 x 88.90 cm)

  • SHIPPING (GROSS) WEIGHT

    71 lbs (32.21 kg)
