USW-112P – Compact Subwoofer

DISCREET SYSTEM ENHANCEMENT

The USW-112P self-powered subwoofer delivers powerful low-frequency performance in a compact, versatile package. It’s designed as an ideal companion for ULTRA‑X20 loudspeaker and complements a range of Meyer Sound loudspeakers including the UPM, UP‑4slim, Ashby‑5C, and Ashby‑8C. Its low-profile cabinet measures just 23.5 inches high by 13.5 inches wide by 12 inches deep, making it an ideal choice when space is limited.

LEAN-AND-CLEAN LOW END

Count on the USW-112P to deliver clean, low-distortion output at any output level: Its proprietary 12” low-distortion, long-excursion driver enhances low-frequency performance in the 35 to 140Hz range, and its cabinet incorporates a low-air-velocity port tuned for high efficiency, linear response, and low distortion.

POTENT PROCESSING

The USW-112P’s built-in Class D amplifier delivers a linear peak SPL of 123 dB, measured using M‑Noise. Sophisticated signal processing includes electronic crossover, correction filters for phase and frequency response, and driver-protection circuitry. The crossover accepts full-range signals, enabling daisy-chain signal distribution and eliminating the need for external crossovers in smaller systems.

AGILITY PLUS STABILITY

The 47-pound USW-112P fits anywhere, from churches and clubs to restaurants and small theatres. Orient it in horizontal or vertical position; its two integrated M8 mounting points can be used with an optional U-bracket to enable wall, ceiling, or truss mounting. Other options include a 35mm stand-mount receptacle with M20 threads for added stability.

Flexible and Feature-Packed
