Meet the Amie Systems

AMIE PRECISION MONITOR

The compact, self-powered Amie Precision Studio Monitor is engineered to excel in critical audio workflows requiring accurate mix translation to a variety of environments. Amie flawlessly reproduces source material at any volume level, and exhibits a remarkable power-to- size ratio as well as true phase linearity for ultra-precise spatial imaging.

AMIE-SUB COMPACT SUBWOOFER

The linear, self-powered Amie‑Sub subwoofer seamlessly complements Amie precision studio monitors to create full-range, multichannel systems with extended response down to 22 Hz. Amie-Sub delivers clean, punchy transients and superior phase coherence, thanks to its single 15-inch, low distortion, long-excursion cone driver; ported bass reflex cabinet; and Class D power amplifier with a suite of signal processing including crossover management, driver protection, and frequency and phase correction.

AN AMIE SYSTEM FOR ANY APPLICATION

Amie systems deliver unparalleled clarity, imaging and depth in a broad range of scenarios from stereo to 7.1 and beyond, from music recording and mixing, to mastering, broadcast, and immersive audio applications. The Amie Precision Studio Monitor’s superior accuracy and high SPL capability make it ideal for translating the linearity and accuracy of large Meyer Sound systems at FOH positions in live sound. Amie systems comply with international standards and recommendations including ITU-R BS.775-3 and SMPTE 202M-1998.

Integration Input Modules

Two optional integrations modules are available for the Amie-Sub loudspeaker.

7.1 INTEGRATION MODULE

Industry standard multi-pin DB-25
5.1 or 7.1 configurations
8-channel, DB25-to-XLR cables
Bass management processing
Dedicated phase matched .1 input for the LFE channel
Selectable +10 dB boost

2.1 INTEGRATION MODULE

2 input channels using XLR connectors
Bass management processing
Dedicated phase matched .1 input for the LFE channel
Selectable +10 dB boost

Amie System Examples

7.1 AMIE SYSTEM (7) Amie Loudspeakers (7) MUB-Amie U-Brackets or Stand Mount Kit (optional) (1) Amie‑Sub with 7.1 Integration Input Module (1) 8 Channel DB-25 to XLR male cable (third party) (1) 8 Channel DB-25 to XLR female cable (third party)	5.1 AMIE SYSTEM (5) Amie Loudspeakers (5) MUB-Amie U-Brackets or Stand Mount Kit (optional) (1) Amie‑Sub with 7.1 Integration Input Module (1) 8 Channel DB-25 to XLR male cable (third party) (1) 8 Channel DB-25 to XLR female cable (third party)	2.1 AMIE SYSTEM (2) Amie Loudspeakers (2) MUB-Amie U-Brackets or Stand Mount Kit (optional) (1) Amie‑Sub with 2.1 Integration Input Module XLR cables (third party)
