Dolby Atmos Connect Interface DAC3202

Liên hệ để báo giá

The Dolby DAC3202 allows you to use legacy amplifiers in Dolby Atmos installations. The Dolby Atmos Cinema Processor CP850 or IMS3000 employ an audio-over-Ethernet protocol to send a digital audio stream to Dolby DAC3202. A DAC3202 converts the digital audio stream to analog audio (up to 32 outputs) for connection to amplifiers.

A Dolby Atmos Cinema Processor CP850 together with a single DAC3202 can support up to 48 speaker feeds (using the 16 analog outputs on the CP850). Installations with more than 48 speaker feeds will need two DAC3202s.

Features

  • DIGITAL AUDIO PROTOCOL

    AES67

  • OUTPUTS

    32 analog audio outputs (4 x DB-25 Female)



  • OUTPUT CONFIGURATION

    Web UI

  • POWER

    12V DC external power supply (72 Watts Max 6 amps)



  • INPUT VOLTAGE

    100-240 VAC; 50-60 Hz

  • MAXIMUM OUTPUT LEVEL

    +20 dBu



  • FREQUENCY RESPONSE

    20 Hz – 20 kHz (+0.5 dB/-1 dB)

  • DYNAMIC RANGE

    108 dB, typical 22 Hz – 22 kHz unweighted



  • ENVIRONMENTAL OPERATING CONDITIONS

    0°C – 40°C (32°F-104°F)

  • ENVIRONMENTAL HUMIDITY CONDITIONS

    20%-80% relative Humidity (noncondensing)



  • UNIT DIMENSIONS

    17.5″ x 8″ x 1 5/8″ (44.1 x 20 x 4.13 cm)

  • SHIPPING DIMENSIONS

    23″ x 11″ x 5 1/4″ (58.5 x 28 x 13 cm)



  • NET WEIGHT

    5.3 lbs (2.4 kg)

  • SHIPPING WEIGHT

    7.5 lbs (3.4 kg)
