Máy chiếu laser Panasonic Solid Shine 10.000 lumens PT-RZ970

Máy chiếu Panasonic PT-RZ970

Liên hệ để báo giá

Laser 1-chip DLP, 10,000 lumens (centre), WUXGA
High brightness and excellent image quality with laser light source
Maintenance free up to 20,000 hours with dust-resistant optical block and long lasting laser engine
Free 360 degrees installation and Geometric Manager Pro function
10,000:1 contrast ratio

Mã sản phẩm: PT-RZ970 Danh mục: Panasonic Thương hiệu: Panasonic

Mô tả

PT-RZ970 là một máy chiếu laser DLP 1-chip. Máy chiếu Panasonic này nổi bật với độ sáng 10.000 lumen (trung tâm), độ phân giải WUXGA, và tỷ lệ tương phản 10.000:1. Nó được thiết kế để tạo ra hình ảnh chất lượng cao với công nghệ DLP và mô-đun laser kép.

Brightness*3	10,000 lumens (Center)2/ 9,400 lumens3 9,400 lumens (Half luminance) (NORMAL) 7,500 lumens (Half luminance) (ECO) 3,700 lumens (Constant luminance) (LONG LIFE1) 3,100 lumens (Constant luminance) (LONG LIFE2) 2,500 lumens (Constant luminance) (LONG LIFE3)
DLP™ Chip \| Panel Size	17.0 mm (0.67 in) diagonal (16:10 aspect ratio)
Power Supply	AC100-240V 3.5A 50/60 Hz
Power Consumption	1,050W NORMAL: 742W ECO: 617W LONG LIFE1: 410-588 LONG LIFE 2: 375-588W LONG LIFE 3: 349-588W SHUTTER: 82W STANDBY MODE [ECO]1: 0.2W STANDBY MODE [NORMAL]: 3W STANDBY MODE (When the [QUICK STARTUP] function is enabled): Approx. 85 W Operating Temperature: 25 °C (77 °F), Altitude: 700m (2,297 ft), ICE62087: 2008 Broadcast contents, Picture mode: Standard, Dynamic Contrast2
BTU Value	Max 3,584 BTU
DLP™ Chip \| Display Method	DLP™ chip × 1, DLP™ system
DLP™ Chip \| Pixels	2,304,000 (1920 × 1200) × 1, total of 1,024,000 pixels
Lens \| PT-RZ970B/W	Powered zoom/focus lenses (1.7-2.4:1), F 1.7-1.9, f 25.6-35.7 mm
Lens \| PT-RZ970LB/LW	Optional powered zoom/focus lenses and xed-focus lens
Light Source	Laser Diode Laser class 1(Class3R for US models) Luminance life for set: 20,000 hours at half luminance (normal)/ 24,000 hours at half luminance (Eco) * Temperature: 30°C (86°F), Altitude 700m (2,297 ft), Dust: 0.15mg/m3 Dynamic Contrast3 43,800 hours at constant luminance (LONG LIFE1) 61,320 hours at constant luminance (LONG LIFE2) 87,600 hours at constant luminance (LONG LIFE3)
Screen Size	1.27- 15.24 m (50-600 inches) (16:10 aspect ratio) 1.27 – 5.08 m (50 – 200 inches) with the ET-DLE055 (16:10 aspect ratio) 2.54 – 7.62 m (100 – 350 inches) with the ET-DLE030 (16:10 aspect ratio)
Brightness	10.000 lumens (centre)/ 9.400 lumens
Center-to-Corner Uniformity*3	90%
Contrast*3	10,000:1 (All White/All Black) (Dynamic Contrast3)
Resolution	1920 × 1200 pixels
Scanning Frequency \| SDI	3G-SDI signal (RGB 4:4:4 12-bit/10-bit): SMPTE ST 424 compliant: 1125(1080)/60i, 1125(1080)/50i,1125(1080)/25p, 1125(1080)/24p, 1125(1080)/24sF, 1125(1080)/30p,[2K/24p], [2K/25p], [2K/30p] 3G-SDI signal (YPBPR4:2:2 10-bit): SMPTE ST 424 compliant: 1125(1080)/60p, 1125(1080)/50p,[2K/48p], [2K/50p], [2K/60p] HD-SDI signal (YPBPR4:2:2 10-bit): SMPTE ST 292 compliant: 750(720)/60p, 750(720)/50p,1125(1080)/60i, 1125(1080)/50i, 1125(1080)/25p, 1125(1080)/24p,1125(1080)/24sF, 1125(1080)/30p SD-SDI signal (YCBCR4:2:2 10-bit): SMPTE ST 259 compliant: 525i(480i), 625i(576i)
Scanning Frequency \| HDMI/DVI-D	fH: 15- 100kHz, fV: 24 – 120Hz, dot clock: 25 – 162 MHz 525i (480i)4, 625i (576i)4, 525p (480p), 625p (576p), 750 (720)/60p,750 (720)/50p, 1125 (1080)/60i, 1125 (1080)/50i, 1125 (1080)/25p,1125 (1080)/24p, 1125 (1080)/24sF, 1125 (1080)/30p, 1125 (1080)/60p,1125 (1080)/50p, VGA (640 x 480) – WUXGA (1920 x 1200) compatible with non-interlaced signals only
Scanning Frequency \| RGB	fH: 15- 100kHz, fV: 24 – 120Hz, dot clock: 20 – 162 MHz
Scanning Frequency \| YPBPR (YCBCR)	525i (480i): fH 15.73 kHz; fV 59.9 Hz, 625i (576i): fH 15.63 kHz; fV 59.9 Hz, 525p (480p): fH 31.50 kHz; fV 60 Hz, 625p (576p): fH 31.25 kHz; fV 50 Hz, 750 (720)/60p: fH 45.00 kHz; fV 60 Hz, 750 (720)/50p: fH 37.50 kHz; fV 50 Hz, 1125 (1080)/60i: fH 33.75 kHz; fV 60 Hz, 1125 (1080)/50i: fH 28.13 kHz; fV 50 Hz, 1125 (1080)/25p: fH 28.13 kHz; fV 25 Hz, 1125 (1080)/24p: fH 27.00 kHz; fV 24 Hz, 1125 (1080)/24sF: fH 27.00 kHz; fV 48 Hz, 1125 (1080)/30p: fH 33.75 kHz; fV 30 Hz, 1125 (1080)/60p: fH 67.50 kHz; fV 60 Hz, 1125 (1080)/50p: fH 56.25 kHz; fV 50 Hz
Scanning Frequency \| Video/S-Video	fH: 15.73 kHz, fV: 59.9 Hz [NTSC/NTSC4.43/PAL-M/PAL60] fH: 15.63 kHz, fV: 50 Hz [PAL/PAL-N/SECAM]
Optical Axis Shift	Vertical: +50%, -16%(powered), Horizontal: +30%, -10% (When using the ET-DLE085/DLE105, +28%, -10%) (powered) NOTE: Optical axis shift function cannot be operated when used with the ET-DLE055. If using the ET-DLE030, the optical axis is fixed.
Installation	Ceiling/floor, front/rear, 360 degree free installation
Terminals \| SDI In	BNC × 1, 3G-SDI signal: SMPTE ST 424 compliant HD-SDI signal: SMPTE ST 292 compliant SD-SDI signal: SMPTE ST 259 compliant
Terminals \| HDMI In	HDMI 19-pin × 1, Deep Color, compatible with HDCP
Terminals \| DVI-D In	DVI-D 24-pin x 1, DVI 1.0 compliant, compatible with HDCP, for single link only
Terminals \| RGB 1 In	BNC × 5
Terminals \| RGB 1 In \| R, G, B	R: 0.7 Vp-p, 75 ohms, G: 0.7 Vp-p (G: 1.0 Vp-p for sync on G), 75 ohms, B: 0.7 Vp-p, 75 ohms HD, VD/SYNC: TTL, high impedance, positive/negative automatic
Terminals \| RGB 1 In \| Y, PB, PR (Y, CB, CR)	Y: 1.0 Vp-p (including sync signal), PB/PR (CB/CR): 0.7 Vp-p, 75 ohms
Terminals \| RGB 1 In \| Y/C	Y: 1.0 Vp-p, C: 0.286 Vp-p, 75 ohms
Terminals \| RGB 1 In \| Video	1.0Vp-p, 75 ohms
Terminals \| RGB 2 In	D-sub HD 15-pin (female) × 1
Terminals \| RGB 2 In \| R, G, B	R: 0.7 Vp-p, 75 ohms, G: 0.7 Vp-p (G: 1.0 Vp-p for sync on G), 75 ohms, B: 0.7 Vp-p, 75 ohms HD, VD/SYNC: TTL, high impedance, positive/negative automatic
Terminals \| RGB 2 In \| Y, PB, PR (Y, CB, CR)	Y: 1.0 Vp-p (including sync signal), PB/PR(CB/CR): 0.7 Vp-p, 75 ohms
Terminals \| Serial/Multi Projector Sync In	D-sub 9-pin (female) × 1 for external control (RS-232C compliant)
Terminals \| Serial/Multi Projector Sync Out	D-sub 9-pin (male) x 1 for link control
Terminals \| Remoter 1 In	M3 jack x 1 for wired remote control
Terminals \| Remoter 1 Out	M3 jack x 1 for link control (for wired remote control)
Terminals \| Remoter 2 In	D-sub 9-pin (female) x1 for external control (parallel)
Terminals \| LAN/DIGITAL LINK	RJ-45 x 1 for network and DIGITAL LINK (video/network/serial control) connection, 100Base-TX, compliant with PJLink™(Class 1) Deep Color, HDCP
Power Cord Length	3.0 m (9 ft 10 in)
Cabinet Materials	Molded plastic
Dimensions (W x H x D)	PT-RZ970B/RZ970W: 498 x 2005 x 581mm (19-19/32 x 7-7/85 x 22-7/8in ) with supplied lens PT-RZ970LB/RZ970LW: 498 x 2005 x 538 mm (19-19/32 x 7-7/85 x 21-3/16in) without lens
Weight	PT-RZ970B/RZ970W: Approx. 23.2kg (51.1lbs) with supplied lens PT-RZ970LB/RZ970LW: Approx. 22.4kg (49.4lbs) without lens
Operation Noise	41dB (37dB[QUIET1] / 35dB[QUIET2])
Operating Temperature	0-45 °C (32-113 °F) * 6
Operating Humidity	10%-80% (no condensation)
Note	1 When the STANDBY MODE is set to Eco, network functions such as power on over the LAN will not operate. 2 The value of the light output at the center region of the projected image is extracted based on the light output measurement method defined by the ISO/IEC 21118:2012 international standards. 3 Measurement, measuring conditions, and method of notation all comply with ISO 21118 international standards. 4 Only compatible with dot clock frequency of 27 MHz (pixel repetition signal). 5 with legs at shortest position. 6 Limits the luminance when used in locations from 0m to 2,700m (0ft to 8,858ft) above sea level at ambient temperatures of 35°C (95°F) or higher, or from 2,700m to 4,200m (8,858ft to 13,780ft) above sea level at ambient temperatures of 25°C (77°F) or higher.
Technology	1-Chip DLP Laser
