PT-EZ770Z là máy chiếu Panasonic tạo ra độ sáng hàng đầu trong phân khúc từ 6.500 lm đến 7.500 lm với tỷ lệ tương phản 5.000:1. Mống mắt tự động điều chỉnh để phù hợp với điều kiện ánh sáng xung quanh. Với độ phân giải màn hình rộng WUXGA 1.920 x 1.200 pixel, PT-EZ770Z/EZ770ZL có khả năng hiển thị video Full HD từ Đĩa Blu-ray và các nguồn khác với chi tiết sống động, đẹp mắt
Thông số kỹ thuật Panasonic PT-EZ770Z
| Brightness | 6,500 lumens (LAMP POWER: AUTO/NORMAL, Dynamic mode, Standard lens) |
|---|---|
| Resolution | 1,920 x 1,200 pixels |
| Power Supply | 100-240 V AC, 50/60 Hz |
| Power Consumption | 590 W (0.3 W with STANDBY MODE set to ECO, 10 W with STANDBY MODE set to NORMAL, 37 W with in STANDBY MODE of Audio Setting set to on.) |
| Optical System | Dichroic mirror separation/prism synthesis system |
| LCD Panel Panel Size | 19.0 mm (0.75 inches) diagonal (16:10 aspect ratio) |
| LCD Panel Display Method | Transparent LCD panel (x 3, R/G/B) |
| LCD Panel Pixels | 2,304,000 (1,920 x 1,200) x 3, total of 6,912,000 pixels |
| LCD Panel Pixel Configuration | Stripe |
| Lens | Powered zoom/focus lens (1.7-2.8:1), F 1.7-2.3, f 26.9-45.4 mm Optional powered zoom/focus lenses and fixed-focus lens |
| Lamp | 400 W UHM lamp |
| Screen Size | 1.02 – 10.16 m (40 – 400 inches), 16:10 aspect ratio (1.52 – 10.16 m (60 – 400 inches) with the ET-ELW22 (16:10 aspect ratio)) |
| Center-to-Corner Uniformity | 90% |
| Contrast | 5,000:1 (full on / full off, LAMP POWER: AUTO, Iris on, Dynamic mode) |
| Scanning Frequency (Display Port/HDMI/DVI-D) | fH: 15-100 kHz, fV: 24-120 Hz, dot clock: 25 MHz-162 MHz (VGA: 640 x 480 pixels to WUXGA: 1,920 x 1,200 pixels, VESA CVT-RB compliant, compatible with HDCP) |
| Scanning Frequency (RGB) | fH: 15-100 kHz, fV: 24-120 Hz, dot clock: up to 162 MHz |
| Scanning Frequency YPBPR (YCBCR) | 480i(525i):fH 15.73 kHz; fV 59.94 Hz, 576i(625i):fH 15.63 kHz; fV 60 Hz, 480p(525p):fH 31.47 kHz; fV 59.94 Hz, 576p(625p):fH 31.25 kHz; fV 50 Hz, 720(750)/60p:fH 45.00 kHz; fV 60 Hz, 720(750)/50p:fH 37.50 kHz; fV 50 Hz, 1080(1125)/60i:fH 33.75 kHz; fV 60 Hz,1080(1125)/50i:fH 28.13 kHz; fV 50 Hz, 1080(1125)/25p:fH 28.13 kHz; fV 25 Hz, 1080(1125)/24p:fH 27.00 kHz; fV 24 Hz, 1080(1125)/24sF:fH 27.00 kHz; fV 48 Hz, 1080(1125)/30p:fH 33.75 kHz; fV 30 Hz, 1080(1125)/60p:fH 67.50 kHz; fV 60 Hz, 1080(1125)/50p:fH 56.25 kHz; fV 50 Hz |
| Scanning Frequency (Video/YC) | fH: 15.73 kHz, fV: 59.94 Hz [NTSC/NTSC4.43/PAL-M/PAL60]; fH: 15.63 kHz, fV: 50 Hz [PAL/PAL-N/SECAM] |
| Optical Axis Shift | Vertical: ±60% (±50% with the ET-ELW22.) (powered), Horizontal: ±10% (powered); NOTE: Optical axis shift function cannot be operated when used with the ET-ELW21. |
| Keystone Correction Range | Vertical: ±40° (with vertical correction only) Horizontal: ±30° (with horizontal correction only) |
| Installation | Ceiling/floor, front/rear |
| Built-in Speaker Size | 3.7 cm (1-15/32 inches) (round) x 1 |
| Built-in Speaker Output Power | 10 W (monaural) |
| Terminals Display Port In | DP-20P x 1, HDCP compatible; 480p(525p), 576p(625p), 720(750)/60p, 720(750)50p, 1080(1125)/60i, 1080(1125)/50i, 1080(1125)/25p, 1080(1125)/24p, 1080(1125)/24sF, 1080(1125)/30p, 1080(1125)/60p, 1080(1125)/50p; VGA(640 x 400) – WUXGA(1,920 x 1,200) Audio signal: linear PCM (sampling frequencies: 48 kHz, 44.1 kHz, 32 kHz) |
| Terminals HDMI In | HDMI 19-pin x 1, Deep Color, HDCP compatible; 480i(525i), 576i(625i), 480p(525p), 576p(625p), 720(750)/60p, 720(750)/50p, 1080(1125)/60i, 1080(1125)/50i, 1080(1125)/25p, 1080(1125)/24p, 1080(1125)/24sF, 1080(1125)/30p, 1080(1125)/60p, 1080(1125)/50p; VGA(640 x 400) – WUXGA(1,920 x 1,200); Audio signal: linear PCM (sampling frequencies: 48 kHz, 44.1 kHz, 32 kHz) |
| Terminals DVI-D In | DVI-D 24-pin x 1, DVI 1.0 compliant, compatible with HDCP, compatible with single link only; 480i(525i), 576i(625i), 480p(525p), 576p(625p), 720(750)/60p, 720(750)/50p, 1080(1125)/60i, 1080(1125)/50i, 1080(1125)/25p, 1080(1125)/24p, 1080(1125)/24sF, 1080(1125)/30p, 1080(1125)/60p, 1080(1125)/50p; VGA(640 x 400) – WUXGA(1,920 x 1,200) |
| Terminals RGB 1 In | D-sub HD 15-pin (female) x 1 |
| Terminals RGB 1 In R, G, B | R: 0.7 Vp-p, 75 ohms; G: 0.7 Vp-p (1.0 Vp-p for sync on G), 75 ohms; B: 0.7 Vp-p, 75 ohms ; HD/VD, SYNC: high impedance, TTL (positive/negative) |
| Terminals RGB 1 Y, PB (CB), PR (CR) | Y: 1.0 Vp-p (including sync signal); PB (CB), PR (CR): 0.7 Vp-p, 75 ohms ; NOTE: SYNC/HD and VD terminals do not accept tri-level sync signals. |
| Terminals RGB 2 In | BNC x 5 (RGB/YPBPR/YCBCR x 1) |
| Terminals RGB 2 In R, G, B | R: 0.7 Vp-p, 75 ohms; G: 0.7 Vp-p (1.0 Vp-p for sync on G), 75 ohms; B: 0.7 Vp-p, 75 ohms; HD/VD, SYNC: high impedance, TTL (positive/negative); NOTE: SYNC/HD and VD terminals do not accept tri-level sync signals. |
| Terminals RGB2 In Y, PB (CB), PR (CR) | Y: 1.0 Vp-p (including sync signal); PB (CB), PR (CR): 0.7 Vp-p, 75 ohms |
| Terminals RGB 2 In S-Video In | Y: 1.0 Vp-p; C: 0.286 Vp-p, 75 ohms |
| Terminals Video In | PIN Jack x 1, 1.0 Vp-p, 75 ohms |
| Terminals Monitor Out | D-sub HD 15-pin (female) x 1 R: 0.7 Vp-p, 75 ohms; G: 0.7 Vp-p (1.0 Vp-p for sync on G), 75 ohms; B: 0.7 Vp-p, 75 ohms; HD/VD, SYNC: high impedance, TTL (positive/negative) |
| Terminals Monitor Out Y, PB (CB), PR (CR) | Y: 1.0 Vp-p (including sync signal); |
| Terminals Audio In | M3 (L, R) x 1, 0.5 Vrms, input impedance: 22 kilohms or more; M3 (L, R) x 1, 0.5 Vrms, input impedance: 22 kilohms or more; PIN Jack (L, R) x 2, 0.5 Vrms, input impedance: 22 kilohms or more |
| Terminals Variable Audio Out | M3 (L, R) x 1 (monitor out: 0-2.0 Vrms, variable) |
| Terminals Serial In | D-sub 9-pin (female) x 1, for external control (RS-232C compliant) |
| Terminals Remoter 1 In | M3 jack x 1 for wired remote control |
| Terminals Remoter 2 In | D-sub 9-pin (female) x 1 |
| Terminals LAN/DIGITAL LINK | RJ-45 x 1 for network and DIGITAL LINK (video/network/serial control) connection, 100Base-TX, compliant with PJLink (class 1),Deep Color, compatible with HDCP, 480i(525i), 576i(625i), 480p(525p), 576p(625p), 720(750)/60p, 720(750)/50p, 1080(1125)/60i, 1080(1125)/50i, 1080(1125)/25p, 1080(1125)/24p, 1080(1125)/24sF, 1080(1125)/30p, 1080(1125)/60p, 1080(1125)/50p; VGA(640 x 400) – WUXGA(1,920 x 1,200), dot clock: 25 MHz-162 MHz ; NOTE: Compatible with non-interlaced signals only. |
| Power Cord Length | 3.0 m (9 ft 10 in) |
| Cabinet Materials | Molded plastic |
| Dimensions (W x H x D) PT-EZ770Z | 530 x 177 x 445 mm (20-7/8 x 6-31/32 x 17-17/32 inches) (with supplied lens) |
| Dimensions (W x H x D) PT-EZ770ZL | 530 x 177 x 385 mm (20-7/8 x 6-31/32 x 15-5/32 inches) (without lens) |
| Weight PT-EZ770Z | Approx. 10.6 kg (23.4 lbs) (with supplied lens) |
| Weight PT-EZ770ZL | Approx. 9.8 kg (21.6 lbs) (without lens) |
| Operation Noise | 37 dB (LAMP POWER: NORMAL), 31 dB (LAMP POWER: ECO 1), 29 dB (LAMP POWER: ECO 2) |
| Operating Temperature | 0℃ – 45℃ (32℉ – 113℉) |
| Operating Humidity | 10% – 80% (no condensation) |
| Technology | LCD |
